Bicycle register  N - O
 ORSA > Harald Ericsson Cykel- & Rep.verkstad HE, Orsa.  ^ back to ORSA in reg.
- - - - - - - - - - - - -
ORSA. - Dalarna.
 Andra towns, villages./ Sveriges landskap. Vykort. • No Vykort, page down.





HARALD

ERICSSON

ORSA

CYKEL- &

REPARATIONS-

VERKSTAD





ORSA

HARALD ERICSSON

HE

CYKEL- &

REP. VERKSTAD





Outboard motors:

Eclipse (Bendix).



TWIN Model TMD



ORSA.





 ORSA.      [Vykort register.]














LIFS Cykel-& Sportaffär. Tel. Orsa 281





Var ligger Orsa på kartan? (back)







T3c
 ORSA.      [Vykort register.]




 TRELLEBORG heter ringen.... bättre finns ingen.















Att plåstra med punkterade ringar är inget flickgöra.

Välj därför ett cykelgummi, som erbjuder den säkraste

garantien för behaglig och bekymmersfri åkning.



Begär uttryckligen TRELLEBORG slang!










 Bicycle brand has nothing in common with outboard motor.
 70 -
 ECLIPSE - USA [Guide: Outboard motors & Bosch spark plugs.]


Bendix Marine Products Company Indiana

Bendix Aviation Corporation Marine Division, Brooklyn, N.Y.





1938 SM W 175 T 3 0,6

1937-39 SMD; TMD W 125 T 4 0,6







- 1936

- 1939







 1936 - ECLIPSE Electric & Mod. SM




Bendix Marine Products Company

Division of Bendix Aviation Corporation

401 Bendix Drive South Bend, Indiana.







ECLIPSE Electric OUTBOARD MOTOR

A BENDIX PRODUKT



Model: SM






 1939 - Eclipse TWIN 5 H.P. & SINGLE 3 H.P.


ECIPSE AIR-COOLED OUTBOARDS



CONDENSED SPECIFICATIONS: The TWIN Model TMD



Horsepower - 5 at 4,000 R.P.M.

Bore and Stroke - 2-1/16" x 1 1/2".

Displacement - 10.02 cu. in.

Weight - 41 lbs.

Ignition  -Bendix-Scintilla Magneto.

Carburetor - Stromberg Float-Feed, high and low speed adjustment. Synchronized one-lever control.

Cooling - Bendix Air-Cooling. Special design flywheel fan.

Exhaust - Under-water, aircooled.

Power Head - Internal rotary valve, 2 port, 2 cycle.

Propeller - Two-Blade, 8 1/4" diameter, 6" pitch, grease seal on propeller shaft. Weedless design.

Gasoline Tank -7 1/2-pint capacity, one hour's operation at full throttle.





The TWIN Model TMD $129.50 at Brooklyn



BENDIX AVIATION CORP.

MARINE DIVITION

754 Lexington Ave. BROOKLYN, N.Y.








ECIPSE AIR-COOLED OUTBOARDS



CONDENSED SPECIFICATIONS: The SINGLE Model SMD



Horsepower - 2 1/2 at 3,300 R.P.M.

Bore and Stroke - 2-1/16" x 1 1/2".

Displacement - 5.01 cu. in. Weight-27 lbs.

Ignition - Bendix-Scintilla Magneto.

Carbureto r- Stromberg Float-Feed Type. High and low speed adjustment with synchronized one-lever control.

Cooling - Bendix Air-Cooling. Special design flywheel fan.

Exhaust - Under-water, air cooled.

Power Head - Internal rotary valve, 2 port, 2 cycle.

Propeller - Two-blade, 7 1/2" diameter, 5" pitch, grease seal on propeller shaft. Weedless design.

Gasoline Tank - 4 1/2-pint capacity, one-piece design die cast aluminum, 1 1/2 hours' operation at full throttle.







The SINGLE Model SMD $79.50 at Brooklyn



BENDIX AVIATION CORP.

MARINE DIVITION

754 Lexington Ave. BROOKLYN, N.Y.







 1939 - ECLIPSE INBOARDS.



ECLIPSE INBOARDS

Complete with built-in Reverse Gear

Power heads identical with Eclipse Outboards, 2 1/2 and 5 H.P., 44 and 56 lbs.

Most compact, surest starting inboards built !



The Single

$119.50

at Brooklyn



The Twin

$159.50

at Brooklyn





BENDIX AVIATION CORP.

MARINE DIVITION 754 Lexington Ave. BROOKLYN, N.Y.
